Eaton B064‑000‑STN – KVM Over IP Remote Console Station

Overview

The Eaton B064‑000‑STN is a KVM over IP remote‑user console station designed for IT infrastructure environments that deploy Eaton/Tripp Lite B064‑IPG series KVM over IP switches. It provides a dedicated user interface for keyboard, video, and mouse access to remote KVM switches without requiring a PC or workstation at the console location. This simplifies secure remote access and eliminates issues associated with general‑purpose computers in control stations (OS patching, malware exposure).

This station supports a single KVM switch connection and provides HDMI video up to 1920 × 1200 @ 60 Hz, four USB ports (keyboard/mouse/peripherals), and Gigabit Ethernet network connectivity. The unit runs from an external 100 – 240 VAC power supply and is qualified for typical server room and rack environments.

B064‑000‑STN fits into rack environments via its desktop form factor with optional rear‑rack (0U) mount plate, or it can sit on a flat surface with rubber feet included. It is deployed at IDF/Server Rooms, data center racks, and network closets alongside B064‑IPG KVM switches to provide local user console access.

The console integrates with Eaton/Tripp Lite IP‑enabled KVM switches and supports features such as virtual media for remote USB storage redirection. It operates from a Java‑free platform, removing dependencies on general‑purpose OS environments and reducing maintenance overhead at console stations.

In practical terms, this device is used where operators require direct visual and control access to servers via a single console without a PC in the workspace — for example in data center NOC stations or consolidation racks. It is not a standalone KVM switch and does not connect directly to servers without a compatible B064‑IPG KVM switch.

Avoid using B064‑000‑STN for multi‑user console switching beyond its intended single‑switch scope or in environments requiring higher‑resolution video beyond 1920 × 1200 without external scaling/conversion.

Key Features

• Remote IP console station for single B064‑IPG KVM switch
• HDMI video up to 1920 × 1200 @ 60 Hz resolution
• Four USB 2.0 console ports for keyboard/mouse/peripherals
• Gigabit Ethernet for IP connectivity and control
• Desktop + optional 0U rack mounting configuration
