Eaton NG5POE-M2 – 2.5G PoE+ Desktop Switch
Overview :
The Eaton NG5POE-M2 is an unmanaged Ethernet switch that provides five 2.5 Gbps RJ45 ports plus one 10 Gbps SFP+ uplink, along with Power over Ethernet (PoE+) support. It is suited for small offices, workgroups, or edge deployments needing both network connectivity and PoE power on limited ports — for example powering IP cameras, VoIP phones, or wireless access points without separate adapters. The switch auto-negotiates link speed and supports auto MDI/MDIX, so you do not need crossover cables or manual configuration. The NG5POE-M2’s compact desktop or wall-mountable metal enclosure makes it practical for cramped networking closets or small racks. With a 70 W total PoE power budget and support for IEEE 802.3af/at/bt standards, it can reliably deliver power and data over the same cables while remaining energy-efficient via IEEE 802.3az support. Its fanless design ensures silent operation — useful in office or recording environments.
Key Features
-
Five 2.5 Gbps RJ45 ports + one 10 Gbps SFP+ uplink
-
PoE+ on four ports, total budget 70 W
-
Auto MDI/MDIX and auto-negotiation on all ports
-
Fanless metal enclosure, desktop or wall-mount use
-
Energy-Efficient Ethernet (802.3az) compliant
