HPE R2H29A
Aruba R2H29A AP‑505 US Campus Access Point – Dual‑Radio Wi‑Fi 6 (802.11ax, 2×2:2 Internal Antennas)
The Aruba AP‑505 (R2H29A) is a Wi‑Fi 6 indoor access point crafted for medium-density environments—like offices, classrooms, and retail locations. Combining robust performance, intelligent RF features, and IoT readiness, it delivers reliable and secure wireless connectivity suitable for modern enterprise needs.
Features
Utilizing 2×2 MIMO radios on both 2.4 GHz and 5 GHz bands, the AP‑505 delivers up to 574 Mbps on 2.4 GHz and 1.2 Gbps on 5 GHz, totaling approximately 1.775 Gbps real-world throughput.
Advanced Options
Its internal downtilt antennas simplify ceiling installations while providing consistent coverage with ~4.9 dBi and ~5.7 dBi gains It includes Bluetooth 5 and Zigbee, making it ideal for indoor IoT use.
Product Key Features
-
Dual‑radio Wi‑Fi 6 (2×2 MIMO) delivering up to 1.775 Gbps aggregate
-
Integrated downtilt internal antennas (4.9 dBi @2.4 GHz, 5.7 dBi @5 GHz)
-
Supports OFDMA, MU‑MIMO, TWT, ClientMatch®, AirSlice®, AirMatch®
-
Enterprise security: WPA3, Enhanced Open, Dynamic Segmentation, onboard TPM
-
Bluetooth 5 and Zigbee radios for IoT use cases
-
Plenum‑rated, ceiling/wall mountable, compact form factor
Reliability & Performance
The AP‑505 supports plenum-rated deployments and operates reliably within 0–50 °C, drawing as little as 4.3 W (DC) or 6.2 W (PoE) in idle and peaking at 14.2 W under load . With intelligent RF enhancements (ClientMatch, AirSlice, AirMatch), it optimizes performance dynamically in high-density areas.
Key Features :
-
Wi‑Fi 6 (802.11ax) dual-radio, 2×2:2 MIMO
-
Aggregate bandwidth ~1.49–1.775 Gbps
-
Integrated downtilt antennas (2.4 GHz & 5 GHz)
-
Bluetooth 5 & Zigbee for IoT/analytics
-
Support for OFDMA, MU‑MIMO, TWT
-
Enterprise-grade security: WPA3, Enhanced Open, Dynamic Segmentation, TPM
-
Plenum rating, ceiling and wall mountable with included bracket
-
Energy-efficient power draw (4.3 W idle, 14.2 W peak)
