HPE JD449A

ProCurve A3000‑24G‑PoE+ Managed Ethernet Switch – 24 × 1 GbE PoE+ Ports + 4 × Shared SFP Uplinks

The HPEJD449A (ProCurve A3000‑24G‑PoE+) is a high-performance, fully managed Layer 3 Ethernet switch offering 24 autoMDIX Gigabit PoE+ ports and 4 shared SFP fiber uplink ports. With a PoE budget up to 370 W, it efficiently powers devices like Aruba APs, IP phones, and cameras. Engineered for SMB, retail, or branch deployments, it supports up to 48 wireless APs or 1,024 users when used as a wireless LAN controller. The device delivers 48 Gbps switching capacity and 35.7 Mpps throughput, featuring advanced Layer 2/3 functionality—such as static/IP routing, RIP, IGMP snooping, VRRP, and ACLs—while offering secure management interfaces including SNMPv3, HTTPS, SSH, VLAN isolation, and RMON.

Features

Designed as a compact 1U rack-mountable switch, the JD449A integrates 24 Gigabit PoE+ ports alongside 4 shared SFP fiber uplinks for flexible uplink options or fiber aggregation. With a full 370 W PoE power budget, it supports multiple high-power devices without external injectors. The switch delivers 48 Gbps switching capacity and sustains 35.7 Mpps forwarding performance, enabling high-density traffic environments.As part of HPE A3000G Wireless LAN Controller family, the switch can centrally manage Aruba APs (up to 48 units or 1,024 clients), simplifying WLAN deployments in distributed offices or small campuses. It supports Layer 3 routing and redundancy protocols—including static routing, RIP‑1/RIP‑2, IGMP v2, and VRRP—for enhanced availability.

Advanced Options

Security and traffic control features include VLANs, port mirroring, ACLs, DiffServ QoS, Auto‑MDIX, and endpoint admission defense (EAD). Administrators can manage the switch using CLI/SSH, SNMP v1/v2c/v3, HTTPS GUI, Telnet, RMON, and management VLAN separation. Expandability is supported via dual expansion slots for future module upgrades.
