HPE JL062-61001
Aruba JL062‑61001 (M330 Dual‑Radio 802.11ac Wireless Access Point
The HPE Aruba JL062‑61001, also known as the M330 Dual‑Radio Access Point, is an indoor enterprise-class Wi‑Fi 5 (802.11ac Wave 2) access point. Equipped with simultaneous 3×3:3 MIMO radios in both the 5 GHz and 2.4 GHz bands, it delivers combined aggregate wireless throughput up to 1.3 Gbps on 5 GHz and up to 450 Mbps on 2.4 GHz, ideal for high-density environments. This AP is great for medium-sized offices, retail, and branch settings. It supports user-friendly clustering technology—allowing up to 16 M330 APs to form a cluster with unified configuration and seamless roaming, all managed via onboard web UI without needing a controller. ([turn0search10]turn0search16)
Features
The M330 features a dual-core 800 MHz ARM CPU along with 256 MB SDRAM and 128 MB flash memory, enabling reliable packet processing and guest portal support. It offers enhanced wireless capacity with support for IEEE 802.11ac and legacy a/b/g/n standards, and supports both IPv4 and IPv6 networks, auto-uplink (auto-MDI/MDI-X), and WDS for flexible deployment scenarios. It is fully manageable via secure HTTPS web UI, CLI/SSH, SNMP v1/v2c, and supports VLANs, multiple SSIDs (up to 8 per radio), and QoS. ([turn0search10]turn0search4)The AP supports PoE (802.3af Class 3) power delivery or optional external power adapter. With 6 internal omni-directional antennas (3 for each band), it offers broad coverage and predictable performance. Guest access portals, advanced encryption (WPA2/WPA3), MAC filtering, RADIUS, and two captive guest portals are built in for secure deployment. Clustering technology simplifies management by automatically synchronizing configurations, SSIDs, and security settings across sites—reducing complexity in distributed deployments. ([turn0search3]turn0search10)
Advanced Options
Designed for SMB and branch environments, the M330 delivers consistent performance with efficient hardware and streamlined firmware. The clustering feature provides redundancy and scalability, avoiding controller dependence and allowing seamless client roaming between clustered units. The device’s internal antenna array and MIMO radios ensure reliable coverage even in dense or RF‑challenging environments. Power draw remains modest at ~13 W, optimizing energy use in PoE-powered deployments. ([turn0search10]turn0search1turn0search16)
Product Key Features
-
Dual‑band, dual‑radio (3×3:3 MIMO) 802.11ac Wave 2
-
1.3 Gbps on 5 GHz + 450 Mbps on 2.4 GHz
-
Clustering support (up to 16 APs) for unified management
-
Single Gigabit RJ‑45 port with PoE (IEEE 802.3af)
-
Up to 8 SSIDs per radio; VLAN segmentation support
-
Enterprise security: WPA2/WPA3, 802.1X, RADIUS, captive portal
Reliability & Performance
Security and manageability are also robust: WPA3 support elevates encryption standards, captive portal options offer flexible guest onboarding, and management via SNMP, CLI, or HTTPS helps adapt to varied administrative preferences. Optional external power ensures flexibility in environments where PoE may not be available. Operating temperature range of 0 °C–40 °C (storage down to –40 °C) and ceiling/wall mounting support make this AP suitable for indoor enterprise use. ([turn0search10]turn0search2turn0search3)
Key Features :
-
Dual‑radio 3×3:3 802.11ac (Wave 2) access point
-
Up to 1.3 Gbps on 5 GHz; 450 Mbps on 2.4 GHz
-
Ethernet: 1 × 1 Gb RJ‑45 with PoE (802.3af)
-
Cluster capability (up to 16 units) without controller
-
8 SSIDs per radio; VLANs, WDS, QoS supported
-
Security: WPA2/WPA3, 802.1X, captive portals, MAC filtering
