HPE Q1P54A 1 × 1 × 8 G4 Rack‑Mountable KVM IP Console Switch (8 Ports)

HPE Q1P54A 1×1×8 G4 IP KVM Console Switch

Overview

The HPE Q1P54A is an enterprise‑grade IP KVM console switch, designed for data centre or rack‑mount environments where remote and local access to multiple servers is required. It provides control over up to 8 connected servers or devices with one local console and one IP user, while supporting cascading for up to 256 servers via two tiering levels. The device fits into a 1 U rack mount or 0 U rear‑ or side‑mount in HPE racks, and is powered via 100–240 V AC auto‑sensing input at 50/60 Hz, consuming up to 100 W maximum. Ideal for server rooms with mixed physical and remote operations, it enables virtual media support, browser‑based management and integration into an existing rack solution. Dimensions are approximately 1.72″ H × 17.0″ W × 6.69″ D and the unit weighs around 4.4 lb, making it suitable for standard 19‑inch rack environments with constrained depth.

Key Features

• 8 independent server ports plus 1 local and 1 remote user simultaneous access.

• Tiering support for up to 256 servers via cascading two levels.

• 100‑240 V AC auto‑sensing input; max power consumption 100 W (approx).

• 1 U rack‑mountable or 0 U side/rear mount compatible with HPE racks.
