Intellinet 210614 – Cat6 Keystone Jack

Overview:

The Intellinet 210614 is a Category 6 (Cat6) Keystone Jack, designed for use with unshielded twisted pair (UTP) cabling. It provides a female RJ45 connection point for network wall plates, patch panels, or surface mount boxes .

Network installers and IT technicians use this keystone jack for terminating horizontal cabling runs in both residential and commercial structured cabling installations. It solves the need for a reliable, standardized connection point that meets higher Cat6 performance specifications, supporting 10G/1G networks at 250 MHz per ISO/IEC 11801 .

The jack features a punch-down style termination compatible with 110 and Krone (LSA) tools and supports 22 to 26 AWG stranded and solid wire . It is 568A/B color-coded and UL listed . The component is ideal for HDBaseT and Power over Ethernet (PoE) applications up to IEEE 802.3bt / PoE++ / Ultra PoE . This jack is not suitable for Cat6A or higher performance cabling standards, nor for outdoor use.

Key Features:

• Cat6 RJ45 module with 250 MHz and 10 Gbps support

• Punch-down style compatible with 110 and Krone tools

• 50 micro-inch gold-plated contacts for reliable connection

• Supports 22-26 AWG solid and stranded wire

• Lifetime warranty for permanent installations
