Netgear GS108X-100NAS 8-Port Gigabit Unmanaged Switch with 10G SFP+ Uplink
Overview?
The Netgear GS108X-100NAS is a high-performance unmanaged switch designed to bridge the gap between standard Gigabit edge connectivity and high-speed 10G core networking. Engineered for small-to-medium businesses (SMBs), branch offices, and professional workstations, this unit addresses the common bottleneck found in traditional 1G networks: the uplink. By providing eight 10/100/1000 Mbps copper ports alongside a dedicated 10G SFP+ fiber port, the GS108X allows for seamless integration of high-bandwidth assets such as Network Attached Storage (NAS), servers, or high-speed uplinks to a core switch.
Deployment is straightforward with a plug-and-play architecture that requires zero software configuration, making it an ideal solution for edge environments where technical resources may be limited. Its non-blocking switching architecture ensures maximum throughput across all ports simultaneously. The rugged metal chassis is fanless, ensuring silent operation in noise-sensitive environments like open-plan offices or conference rooms. Whether utilized as a desktop unit or mounted in a standard rack, the GS108X provides a cost-effective path to 10G adoption without the complexity of managed networking.
Key Features
- – Dedicated 10G SFP+ port for high-speed core connectivity.
- – Fanless metal housing for silent, reliable operation.
- – Energy Efficient Ethernet (IEEE 802.3az) power savings.
- – Versatile desktop, wall, or rack-mount installation.
- Brand Netgear
- Part Number GS108X-100NAS
- Product Type Unmanaged Network Switch
- Total Ports 9 (8 x 1GbE, 1 x 10G SFP+)
- Switching Capacity 36 Gbps
- MAC Address Table 16K entries
- Packet Buffer 1.5 MB
- MTBF 2,829,323 hours
- Power Consumption 7.24 W (Maximum)
- Dimensions 236 x 102 x 27 mm
- Weight 0.60 kg
- Operating Temperature 0? to 40? C
- Compliance IEEE 802.3az (Energy Efficient Ethernet)
- Frequently Asked Questions
- Does the GS108X-100NAS support Power over Ethernet (PoE)? No, this model is a non-PoE switch. It is designed for high-speed data transport and does not provide power to connected devices like IP cameras or Access Points.
- Can the 10G SFP+ port be used with a Direct Attach Copper (DAC) cable? Yes, the SFP+ port is compatible with standard 10G SFP+ DAC cables as well as SFP+ fiber transceivers, providing flexibility for short-range or long-range uplinks.
- Is this switch rack-mountable? Yes, the GS108X-100NAS includes a rack-mount kit in the box, allowing it to be installed in a standard 19-inch networking rack, in addition to desktop or wall-mount options.
