Opengear OM1308-8E – OM1300 Operations Manager (8 Serial, 8 GbE Switch, Dual 1GbE/SFP Uplinks)

Overview :

The Opengear OM1308-8E is an all-in-one, compact Operations Manager appliance designed specifically for edge environments, remote branch offices, retail locations, and industrial deployments. By integrating 8 RJ45 RS-232 serial console ports with a managed 8-port Gigabit Ethernet switch into a single fanless 1U half-depth chassis, the OM1308-8E provides resilient Smart Out-of-Band (Smart OOB™) management and local network consolidation without requiring separate switching hardware.

Powered by an ARM Cortex-A53 quad-core 1.6 GHz processor with 4 GB LPDDR4 RAM, 32 GB eMMC storage, and an embedded TPM 2.0 cryptoprocessor, the OM1308-8E supports edge automation workflows including Python scripting and Docker containers. NetOps teams can manage and orchestrate the unit remotely through Opengear Lighthouse software to ensure reliable access and rapid remediation during primary WAN outages.

Key Features :

• Integrated Serial & Switching: Combines 8 software-selectable RS-232 serial ports with an 8-port 10/100/1000 Mbps Gigabit Ethernet switch.

• Dual Gigabit Uplinks: Equipped with 2 x combo 1GbE RJ45 / SFP ports for redundant wired primary and failover WAN/LAN connections.

• NetOps & Edge Automation: Supports Docker containers and Python scripts directly on the appliance for local automated remediation.

• Hardware Security: Integrated TPM 2.0 module safeguards encryption keys, secure boot, and hardware-accelerated VPN connections.

• Centralized Management: Integrates natively with Opengear Lighthouse for zero-touch provisioning and cloud-based management.

• Fanless Compact Form Factor: Silent, passive-cooled 1U half-depth design suitable for space-constrained desktop or rack deployments.
