Ruckus ICX7550-24F-E2-R3 24-Port Managed Switch

Ruckus ICX7550-24F-E2-R3 – 24-Port 1/10G SFP+ Managed Switch

Overview :

The Ruckus ICX7550-24F-E2-R3 is a high-performance, stackable Layer 3 managed switch designed for enterprise and campus networks requiring robust fiber aggregation. It features 24 ports of 1/10 Gbps SFP+ connectivity, ideal for high-throughput applications such as data centers, server farms, and high-density wireless deployments. The switch supports up to 12 units per stack, offering scalable bandwidth and simplified management. With two 40/100 Gbps QSFP+ dual-mode uplink/stacking ports, it ensures future-ready connectivity for backbone and inter-switch links. The modular design includes a slot for optional expansion modules, providing flexibility for evolving network needs. The device is equipped with redundant hot-swappable power supplies and fans, ensuring high availability and reliability. Its compact 1U form factor allows for efficient rack-mount deployment in space-constrained environments. The ICX7550-24F-E2-R3 is suitable for organizations seeking a balance between performance, scalability, and cost-effectiveness in their network infrastructure.

Key Features :

• 24 x 1/10 Gbps SFP+ Ports: High-density fiber connectivity for demanding applications.

• Dual 40/100 Gbps QSFP+ Uplinks: Supports high-speed stacking and uplink requirements.

• Modular Expansion Slot: Allows for future-proofing with optional modules.

• Redundant Power & Cooling: Hot-swappable components for enhanced reliability.

• Stackable Architecture: Up to 12 units per stack for scalable performance.
