StarTech 2M2-REMOVABLE-PCIE Dual-Bay Removable Drive Enclosure for M.2 NVMe SSDs PCIe x8 Card

Overview :

The StarTech 2M2-REMOVABLE-PCIE is a specialized storage solution designed for high-speed data mobility and security. It is utilized by data scientists, video editors, and forensic investigators who need to frequently swap M.2 NVMe drives between systems or physically secure sensitive data by removing the storage media when not in use.

Technically, the device consists of a PCIe x8 expansion card that houses two independent, removable drive trays. It supports M.2 NVMe SSDs (M-Key) in various lengths (2230, 2242, 2260, 2280). Utilizing the PCIe 4.0 standard, it provides high-bandwidth performance with speeds up to 64Gbps (when using a compatible PCIe 4.0 motherboard). The card features a PCIe bifurcation requirement, meaning the motherboard must support splitting the x8 slot into x4/x4 mode to recognize both drives simultaneously. Each tray is equipped with a key lock to prevent unauthorized removal and ensure the drive remains seated during operation.

Deployment is intended for standard-profile desktop towers or rackmount servers. The removable trays fit into a single-slot PCIe expansion bay, providing “hot-swap” capability (provided the OS and motherboard BIOS support it). To maintain optimal performance and prevent thermal throttling of high-speed NVMe drives, the card includes integrated thermal pads and a vented aluminum design for passive heat dissipation.

Key Features :

• Dual-bay design allows for two independent M.2 NVMe SSDs in one PCIe slot.

• Removable drive trays enable quick drive swapping and secure data storage.

• PCIe 4.0 x8 interface supports maximum data transfer speeds.

• Key-lockable trays provide physical security against drive theft or accidental removal.

• Aluminum construction and thermal pads for efficient SSD cooling.
