StarTech BNDTB4M2E1 External Thunderbolt 3 NVMe Enclosure
Overview
The StarTech BNDTB4M2E1 is a high-performance external storage solution that combines the StarTech Thunderbolt 3 PCIe Expansion Chassis (TB31PCIEX16) with a PCIe M.2 SSD adapter card (PEX4M2E1). This bundle allows users to connect internal PCIe M.2 NVMe or AHCI solid-state drives to a Thunderbolt 3 equipped laptop or desktop, providing ultra-fast data access and significant storage expansion without opening the host computer.
By leveraging the 40Gbps bandwidth of Thunderbolt 3, this adapter ensures that high-speed M.2 drives operate at peak performance, making it an ideal tool for creative professionals handling large raw video files, 4K content, or massive datasets. The chassis also features a dedicated DisplayPort output and a second Thunderbolt 3 port, allowing for the daisy-chaining of additional peripherals or the connection of up to two 4K displays to streamline multitasking.
The enclosure is constructed from durable aluminum and steel and includes an integrated 92mm cooling fan to maintain optimal operating temperatures for the internal SSD and PCIe circuitry. It is a plug-and-play solution that requires no drivers for the chassis itself, though it does require a host system with a functional Thunderbolt 3 port.
Key Features
-
External Thunderbolt 3 to M.2 NVMe/AHCI SSD expansion.
-
Supports 2242, 2260, 2280, and 22110 M.2 drive form factors.
-
Includes dedicated DisplayPort output for an additional monitor.
-
Secondary Thunderbolt 3 port supports daisy-chaining or USB-C devices.
-
Rugged aluminum and steel housing with integrated 92mm cooling fan.
