TRENDnet TC-P12C6V – 12‑Port Cat6 Wall‑Mount Patch Panel
Overview :
The TRENDnet TC-P12C6V is a 12‑port unshielded Category 6 patch panel designed for wall‑mount installations in small to medium business (SMB) or branch environments. It allows engineers to consolidate multiple RJ‑45 terminations in a compact form‑factor with a 10‑inch‑wide chassis and included 89D bracket for vertical or horizontal mounting. The unit supports both T568A and T568B wiring schemes and uses 110/ Krone‑type IDC termination blocks for solid or stranded 22‑26 AWG copper. With a rated bandwidth of 250 MHz and support for up to 10 Gbps at shorter distances, it is suited for modern multi‑gigabit deployments on Cat6 cabling. The panel also includes cable‑management features (pass‑through holders, cable ties, label areas) for structured cabling setups. Firmware or software management isn’t applicable here, so it integrates simply as a passive termination point in wiring closets, server rooms, or edge‑branch wiring hubs.
Key Features
-
12 RJ‑45 Cat6 ports on a 10‑inch wall‑mount chassis
-
Supports up to 5 Gbps @100 m and 10 Gbps @55 m on Cat6 cabling
-
Color‑coded T568A/T568B wiring and 110/ Krone IDC termination
-
Includes 89D bracket for vertical or horizontal mount configuration
-
SPCC steel construction with integrated cable ties and labeling surface
