Vertiv UI30007L Updu Monitored 24 Ulock C13 6 Ulock C19

Overview :

The Vertiv Geist UI30007L Universal Power Distribution Unit (Vertiv Geist UPDU) is a versatile rack power distribution unit (rPDU) with a universal input and a max power capacity of 22kW. This universal rPDU enables fast and easy installation since it supports common AC power configurations ranging from 16A-63A and 120V-415V in both single phase and three phase configurations. Just choose the right Facility Side Cable (sold separately) to define the input power configuration you need to install the Vertiv Geist UPDU in your network system. This model has 24 locking C13 and 6 locking C19 receptacles, all equipped with the Vertiv patented U-Lock to lessen accidental disconnections. The hot-swappable Interchangeable Monitoring Device (IMD) on this intelligent rack PDU not only has ports for unit-level remote power monitoring and environmental monitoring, but it also provides peace of mind that you can seamlessly update the unit’s technology to adapt to your changing business needs.

BrandVertiv Liebert
SKUUI30007L
ConditionNew
Dimensions2.3 × 2 × 2.3 in
Weight21 lbs
Product NameUpdu Monitored 24 Ulock C13 6 Ulock C19
Manufacturer Part NumberUI30007L
Product TypePDU
PhaseThree Phase
Receptacle TypeU-Lock IEC 60320 C13 U-Lock IEC 60320 C19
Product FamilyrPDU
TAA CompliantYes
Energy StarNo
PDU TypeMonitored
Remote Outlet SwitchingNo
Mounting OrientationVertical
Power Rating (Watt)22 kW
Locking ReceptaclesIEC 60320 C13 IEC 60320 C19
Receptacle Detail24 x U-Lock IEC 60320 C13 6 x U-Lock IEC 60320 C19
Rack Height0U
Plug / Connector TypeUniversal Input
Input Voltage Range230 V AC - 415 V AC
Input Current63 A
Length70"
Mount TypeRack-mountable
Protection TypeOvercurrent Protection Double Pole
Input Voltage230 V AC 415 V AC
Environmentally FriendlyYes
Network (RJ-45)Yes
Plug / Connector Detail1 x Universal Input
Country of OriginUnited States
Width2"
Depth2.3"
Product SeriesrPDU
Product ModelDU03E4W1-30PN67- 2S02A9K00-S-A
