APC AP9570 – 1U 30A 208V Basic Rack PDU

Overview :

The APC AP9570 is a basic rack-mounted power distribution unit (PDU) designed for reliable delivery of 208V AC power to rack-based IT equipment. It distributes power from a single high-capacity input to multiple high-current outlets, supporting enterprise-grade hardware.

With a 30A input and up to ~4.99kVA load capacity, this unit is equipped with four IEC C19 outlets, making it suitable for high-power servers, blade systems, and networking equipment. It includes a NEMA L6-30P input plug and integrated overload protection via resettable circuit breakers.

The 1U horizontal form factor fits standard 19-inch racks, making it ideal for data centers, colocation environments, and high-density enterprise deployments where 208V distribution is standard.

This is a basic PDU (no monitoring or switching), so it is not suitable for environments requiring remote management, outlet-level control, or power metering.

Key Features :

30A 208V input supports high-density IT loads
Four C19 outlets for high-power equipment
1U rack-mount design for standard enclosures
Resettable breaker enables fast overload recovery
Single input feed simplifies rack power design
