Eaton EVMIGU23X Universal Input Metered Rack PDU 42 Outlets

Eaton EVMIGU23X Universal Input Metered Rack PDU 42 Outlets

Overview

The Eaton EVMIGU23X is a universal-input, metered rack power distribution unit (PDU) designed for global applications and mixed power environments. It accepts power input ranging from 100 – 240 V single-phase up to 173 – 415 V three-phase and supports outputs from roughly 5 kVA up to 23 kVA depending on the cord set used and configuration.With 42 outlets—24 IEC C13 plus 18 high-retention IEC C39 combo outlets (which accept C14 or C20 plugs)—the unit gives flexibility in connecting standard IT gear as well as higher-power equipment without needing a mix of PDUs.The chassis is a 0 U vertical mount (≈ 72″ tall, ~2″ wide) which allows installation at the rear or side of a standard rack without consuming rack-U space—ideal for dense equipment racks where every U mattersIt’s built for data-centre engineering teams who deploy racks worldwide and want one PDU model that adapts to local input standards, supports remote metering, management and load-balancing, and future-proofs deployments as power demands grow.

Key Features

• Universal‐input design supports 5 kVA (single-phase) up to 23 kVA (three-phase) and wide input voltage range, so one model works globally.

• 42 outlets (24 C13 + 18 high-retention C39 combo) provide mixed device support in one unit and reduce the number of PDUs required.

• 0U vertical mounting preserves rack unit space for IT gear and installs neatly at rear/side of standard racks.

• Built-in metering (voltage, current, power, energy), Gigabit network interface, daisy-chain up to 40 units, advanced cybersecurity including chain-of-trust firmware.
