INTELLINET 509220 – Outdoor PoE-Powered 5-Port Gigabit Switch

Overview :

The INTELLINET 509220 Outdoor PoE-Powered 5-Port Gigabit Switch provides high-speed network expansion and remote power distribution in demanding outdoor environments.

Featuring PoE passthrough technology, this switch draws up to 90 W of power over its 802.3bt PD input port from a PoE++ switch or injector—eliminating the need for local AC power outlets. It extends network connectivity up to an additional 100 m (328 ft.) while supplying up to 85 W total power budget across four IEEE 802.3at/af compliant PoE+ output ports for IP cameras, wireless access points, and IoT devices. Encased in a rugged IP65-rated, NEMA 4 weatherproof housing, it withstands extreme temperatures, heavy rain, and dust.

Key Features :

• Outdoor PoE-powered switch operating entirely via PoE passthrough technology.

• Receives up to 90 W power input via IEEE 802.3bt (4PPoE / PoE++) on Port 5.

• Delivers up to 30 W per port with an 85 W total PoE power budget across 4 PSE output ports.

• Extends network range between PoE source and end devices from 100 m to 200 m (656 ft.).

• Weatherproof IP65 / NEMA 4 rated dustproof and waterproof enclosure.

• Wide operating temperature range of -40°C to 80°C (-40°F to 176°F).

• Includes integrated mounting brackets for flexible wall and pole installation.

• Plug-and-play, unmanaged deployment with no configuration needed.
