INTELLINET 562102 – 10-Port PoE+ Switch

Overview :

The INTELLINET 562102 10-Port PoE+ Switch delivers power and Fast Ethernet connectivity for IP surveillance cameras, VoIP phones, and wireless access points.

Equipped with 8 IEEE 802.3at/af-compliant PoE+ ports and 2 dedicated Fast Ethernet RJ45 uplink ports, it provides a 95 W total power budget with up to 30 W output per port. Despite being an unmanaged switch, it features an integrated Powered Device Monitor (PDM / PD Alive Check) that automatically monitors and restarts unresponsive connected PoE devices to reduce maintenance downtime. A front-panel slide switch allows easy hardware toggling between Default, Port Isolation (VLAN), and PoE Extend Mode (extending reach up to 250 m / 820 ft.).

Key Features :

• 8 Fast Ethernet PoE+ ports supplying both data and power over standard Ethernet cables.

• 2 dedicated RJ45 Fast Ethernet uplink ports for connecting to routers or additional switches.

• Total PoE power budget of 95 W with up to 30 W available per port.

• Self-Healing Powered Device Monitor (PDM) automatically power-cycles non-responsive PoE equipment.

• Hardware DIP switch modes:

  • Default: Standard full-communication switch operation.

  • VLAN: Isolates ports 1 to 8 from each other while maintaining communication with uplink ports 9 & 10.

  • PoE Extend: Extends transmission distance up to 250 m (820 ft.) at 10 Mbps.

• Compact, fanless design for quiet desktop or wall-mount deployment.
