Ruckus ICX7850-48FS-E2 Ethernet Switch 48-Port Managed Rack-Mountable

Ruckus ICX7850-48FS-E2 48 Port 10G SFP Switch with 8 100G QSFP28

Overview

The Ruckus ICX7850-48FS-E2 is a high-performance, fixed-form-factor Ethernet switch designed for demanding aggregation and core network deployments. It features 48 10G SFP+ ports and 8 100G QSFP28 ports, delivering a total switching capacity of 2.56 Tbps. This makes it suitable for high-density environments such as data centers or enterprise campus cores. The switch supports advanced Layer 3 routing protocols, including OSPF, BGP, and VRF, and offers features like MACsec encryption for enhanced security.high-density environments such as data centers or enterprise campus cores. The switch supports advanced Layer 3 routing protocols, including OSPF, BGP, and VRF, and offers features like MACsec encryption for enhanced security.

Key Features

• 48x 10G SFP+ Ports: Provides high-density connectivity for servers and network devices.

• 8x 100G QSFP28 Ports: Supports high-speed uplinks or stacking with breakout capabilities to 4x10G or 4x25G.

• 2.56 Tbps Switching Capacity: Ensures non-blocking, line-rate performance across all ports.

• MACsec Encryption: Offers 128/256-bit data encryption for secure communications.

• Advanced Layer 3 Features: Supports OSPF, BGP, VRF, and VXLAN for scalable and flexible network architectures.

• Stacking Support: Allows up to 12 units in a stack with 9.6 Tbps aggregate bandwidth.

• Hot-Swappable Components: Includes redundant, load-sharing power supplies and fan modules for high availability.
