Eaton 9PX1000RT 1 kVA ups 9px1000rt W Online Double Conversion UPS
Overview
The Eaton 9PX1000RT is a compact 2-U rack/tower convertible online double-conversion UPS designed for critical IT loads in server rooms, edge cabinets or network closets where space is at a premium but reliability is essential. Rated at 1000 VA / 900 W and operating at 120 V input/output with a 0.9 power factor, it delivers true sine-wave output with full voltage regulation, ensuring servers, storage arrays and network equipment remain protected during brown-outs, blackouts or line noise. The unit includes sealed lead-acid, hot-swappable internal battery modules and supports up to four external battery modules for extended runtime. Its advanced ABM® battery-management technology lengthens battery service life by approximately 50%. With included 4-post rack rails and optional pedestal feet, the 9PX1000RT installs easily in standard 19″ racks while preserving U-space for equipment.
Key Features
-
1000 VA / 900 W capacity (0.9 power factor) supports high-density IT loads in compact format.
-
Online double-conversion topology with true sine-wave output and ±1% voltage regulation—protects sensitive gear under all conditions.
-
Hot-swappable internal batteries plus support for up to four external battery modules give scalable runtime.
-
ABM® battery-management technology extends battery life and provides proactive warning of battery replacement.
-
Rack/tower dual mounting (2 U height) with included rail kit fits both standard cabinets and stand-alone deployments.
