Ruckus ICX7150-24P-2X10G 24 ports managed switch rack mountable

Ruckus ICX7150-24P-2X10G 24 ports managed switch rack mountable Multi 10 GbE Uplinks

Overview

The RUCKUS ICX7150-24P-2X10G is a 24-port PoE+ gigabit access switch designed for access-layer deployments in campus wiring closets or branch offices where you need PoE to power APs/cameras and high-bandwidth uplinks. It offers 24 × 10/100/1000 Mbps RJ-45 PoE+ ports with a 370 W PoE budget, plus uplink flexibility via 2 × 1 Gb RJ-45 uplinks, 2 × 1 Gb SFP, and 2 × 10 Gb SFP+ stacking/uplink ports (upgradable to 4×10 Gb SFP+ with license). In real-world terms: plug 24 end-devices (IP cameras, PoE APs, VoIP phones) into the RJ-45 ports, then use the 10 Gb uplinks to handle aggregation to the core/aggregation layer, or stack multiple units into a single logical switch for simplified management.budget, plus uplink flexibility via 2 × 1 Gb RJ-45 uplinks, 2 × 1 Gb SFP, and 2 × 10 Gb SFP+ stacking/uplink ports (upgradable to 4×10 Gb SFP+ with license). In real-world terms: plug 24 end-devices (IP cameras, PoE APs, VoIP phones) into the RJ-45 ports, then use the 10 Gb uplinks to handle aggregation to the core/aggregation layer, or stack multiple units into a single logical switch for simplified management.

Key Features

• 24 × 1 Gb RJ-45 PoE+ ports supporting up to 370 W total PoE budget.

• 2 × 10 Gb SFP+ uplinks (stacking/uplink) built-in, with license option to upgrade to 4 × 10 Gb SFP+ uplinks

• Full stacking support: up to 12 switches per stack, with aggregate stacking bandwidth up to ~480 Gbps.

• Layer 3 static routing (RIP) support out of the box; licence upgrade options available for advanced L3 (OSPF, VRRP, PIM) on higher SKUs.

• Fan-less or quiet mode design (depending on configuration/model) suitable for noise-sensitive environments like retail floors or conference rooms.
